Operational Amplifiers: Key Characteristics and Parameters There are many different important characteristics and parameters related to op amps see Figure 1. These characteristics are described in greater detail below. This means the feedback path, or loop, is open. Voltage comparators compare the input terminal voltages. Even with small voltage differentials, voltage comparators can drive the output to either the positive or negative rails. High open-loop gains are beneficial in closed-loop configurations, as they enable stable circuit behaviors across temperature, process, and signal variations.
Input impedance is measured between the negative and positive input terminals, and its ideal value is infinity, which minimizes loading of the source. In reality, there is a small current leakage. Arranging the circuitry around an operational amplifier may significantly alter the effective input impedance for the source, so external components and feedback loops must be carefully configured.
It is important to note that input impedance is not solely determined by the input DC resistance. Input capacitance can also influence circuit behavior, so that must be taken into consideration as well. However, the output impedance typically has a small value, which determines the amount of current it can drive, and how well it can operate as a voltage buffer. Frequency response and bandwidth BW An ideal op amp would have an infinite bandwidth BW , and would be able to maintain a high gain regardless of signal frequency.
Op amps with a higher BW have improved performance because they maintain higher gains at higher frequencies; however, this higher gain results in larger power consumption or increased cost. These are the major parameters to consider when selecting an operational amplifier in your design, but there are many other considerations that may influence your design, depending on the application and performance needs.
Other common parameters include input offset voltage, noise, quiescent current, and supply voltages. Negative Feedback and Closed-Loop Gain In an operational amplifier, negative feedback is implemented by feeding a portion of the output signal through an external feedback resistor and back to the inverting input see Figure 3. This is because the internal op amp components may vary substantially due to process shifts, temperature changes, voltage changes, and other factors.
Op amps have a broad range of usages, and as such are a key building block in many analog applications — including filter designs, voltage buffers, comparator circuits, and many others. In addition, most companies provide simulation support, such as PSPICE models, for designers to validate their operational amplifier designs before building real designs.
The limitations to using operational amplifiers include the fact they are analog circuits, and require a designer that understands analog fundamentals such as loading, frequency response, and stability. It is not uncommon to design a seemingly simple op amp circuit, only to turn it on and find that it is oscillating.
Due to some of the key parameters discussed earlier, the designer must understand how those parameters play into their design, which typically means the designer must have a moderate to high level of analog design experience. Operational Amplifier Configuration Topologies There are several different op amp circuits, each differing in function.
The most common topologies are described below. Voltage follower The most basic operational amplifier circuit is a voltage follower see Figure 4. This circuit does not generally require external components, and provides high input impedance and low output impedance, which makes it a useful buffer.
Because the voltage input and output are equal, changes to the input produce equivalent changes to the output voltage. Inverting and non-inverting configurations are the two most common amplifier configurations. In other words, it will be stochastically distributed within the defined range.
Slew Rate SR The slew rate is a parameter that describes the operating speed of an opamp. It represents the rate that can change per unit time stipulated by the output voltage. Ideal opamps make it possible to faithfully output an output signal for any input signal.
However, in reality slew rate limits do exist. When supplying a rectangular pulse at the input with a steep rise and fall, this indicates the possible degree of change in the output voltage per unit time.
